M55 SERIES

Feature

• A kind of safety valve capable of preventing malfunctioning.

Being a semi-automatic type, the valve does not operate freely like an ordinary solenoid valve by turning on or off of the power.

• Constant power consumption.

As a direct-acting, manual-reset type three-way valve is used as the pilot valve, power consumption is kept constant, irrespective of the valve size.

• Packed type

Free from any fear of burnout or insulation degradation as the coil and movable core do not come into contact with fluid.

• Easy to operate manually.

Can be latched with the push of the palm button.
Available in two types ― no voltage release and electrically tripped.

Standard specification

Body Material: Cast Bronze (Gun Metal)

Fluid: Clean Air

Ambient Temperature: -20 ~ 60℃

Working Pressure: 0.12 ~ 0.99MPa
