SLIM SERIES

Feature

• Built as hermetically sealed, pressure-resistant containers, these level gauges can be safely used in gas/vapor explosion hazardous areas (classes I and II).
• Safe and reliable operation owing to use of magnetic force only.
• Varying liquid levels can be identified owing to red and white markings.
• Compact and light, therefore, easy to install and remove.
• An explosion-proof type or ordinary type reed switch can be attached.

Standard specification

Fluid : water, oil, chemicals

Max. Working pressure : 3.0MPa

Max. Liquid temperature : 150℃

Specific gravity of liquid :

• 2 ～ 0.7(FLOAT MATERIAL ：SUS316L)
• 2 ～ 0.8(FLOAT MATERIAL ：FRP or equivalent)

Body material : SUS304
